XL260 is an IoT device leveraging MQTT and LoRa communication protocols for data monitoring. This compact device designed to handle multiple sensors, ensuring seamless tracking of temperature, electric current, pressure, vibration, and digital inputs. The XL260’s relay switch port empowers remote control of external devices, allowing broad possibilities to make some automation. With redundant MQTT and LoRa protocols, rest assured that the data transmission remains secure and uninterrupted.
- Overview
- Specifications
- Firmware
- Manual
- Case Studies
Overview
Sensor Diversity
Integrate up to 37 sensors seamlessly. With 12 temperature sensors ports, 4 digital input sensors ports, 2 pressure sensors ports, 3 vibration sensor ports, 4 relay switch ports, 12 current sensor Ports
Alarm
A built-in alarm system that can be controlled via IoT platform.
Communication Protocol Redundancy
The XL260 is communicating using Wi-Fi, and LoRa so the device has a redundancy communication protocol.
Over The Air (OTA) Firmware Update
New firmware can be installed on the device.
Specifications
| Power Requirements | Temperature Sensor Ports |
|---|---|
|
|
| Digital Input Sensor Ports | Pressure Sensor Ports |
|
|
| Vibration Sensor Ports | Relay Switch |
|
|
| CT Sensor Ports | LED Indicators |
|
|
| Dimension | Protocol |
|
|
Firmware
IMPORTANT: Installing different firmware may cause the device to malfunction. Always install the latest version to maintain optimal performance.
| Firmware | Release Date | Note |
|---|---|---|
| XL260-multi-sensor.v.2.0 | 22 May 2024 |
|
| XL260-multi-sensor.v.1.1 | 27 Dec 2023 |
|
| XL260-multi-sensor.v.1.0 | 17 Nov 2023 |
|
Case Studies
This case study explores the practical applications of the XL260 device in data monitoring, automation, and remote-control scenarios.
Data Monitoring Application
The XL260 device proves invaluable in data monitoring and tracking scenarios:
- Industrial Monitoring:
By deploying XL260 devices in industrial settings, it becomes possible to track crucial parameters such as temperature, electric current, pressure, and vibration. This enables proactive maintenance, identifies potential issues, and optimizes operational efficiency. - Energy Monitoring:
With its capability to track electric current, the XL260 device is well-suited for energy monitoring applications. It can measure power consumption in residential or commercial buildings, enabling users to identify energy inefficiencies and make informed decisions to optimize energy usage.
Automation Application
The XL260 device enhances automation capabilities in various settings:
- Home Automation
By integrating the XL260 device with other home automation systems, homeowners can remotely control devices based on the collected data. For example, temperature sensors can trigger HVAC systems, electric current measurements can activate or deactivate appliances, and vibration sensors can detect anomalies and alert homeowners. - Industrial Automation:
In industrial automation scenarios, the XL260 device can be used to automate processes based on real-time data. For instance, it can trigger alarms or activate machinery based on predefined thresholds of temperature, electric current, or pressure.
Remote Control Application
The XL260 device enables remote control of external devices:
- Smart Home Control:
Through the device’s relay switch port, users can remotely control external devices, such as lights, fans, or security systems. This enables convenient and efficient management of home systems from a central location or through a mobile application. - Industrial Applications:
The XL260 device’s remote-control capabilities find application in industries where controlling external devices is essential, such as controlling pumps, valves, or machinery in remote locations.
Overview
Overview
Sensor Diversity
Integrate up to 37 sensors seamlessly. With 12 temperature sensors ports, 4 digital input sensors ports, 2 pressure sensors ports, 3 vibration sensor ports, 4 relay switch ports, 12 current sensor Ports
Alarm
A built-in alarm system that can be controlled via IoT platform.
Communication Protocol Redundancy
The XL260 is communicating using Wi-Fi, and LoRa so the device has a redundancy communication protocol.
Over The Air (OTA) Firmware Update
New firmware can be installed on the device.
Specifications
Specifications
| Power Requirements | Temperature Sensor Ports |
|---|---|
|
|
| Digital Input Sensor Ports | Pressure Sensor Ports |
|
|
| Vibration Sensor Ports | Relay Switch |
|
|
| CT Sensor Ports | LED Indicators |
|
|
| Dimension | Protocol |
|
|
Firmware
Firmware
IMPORTANT: Installing different firmware may cause the device to malfunction. Always install the latest version to maintain optimal performance.
| Firmware | Release Date | Note |
|---|---|---|
| XL260-multi-sensor.v.2.0 | 22 May 2024 |
|
| XL260-multi-sensor.v.1.1 | 27 Dec 2023 |
|
| XL260-multi-sensor.v.1.0 | 17 Nov 2023 |
|
Manual
Case Studies
Case Studies
This case study explores the practical applications of the XL260 device in data monitoring, automation, and remote-control scenarios.
Data Monitoring Application
The XL260 device proves invaluable in data monitoring and tracking scenarios:
- Industrial Monitoring:
By deploying XL260 devices in industrial settings, it becomes possible to track crucial parameters such as temperature, electric current, pressure, and vibration. This enables proactive maintenance, identifies potential issues, and optimizes operational efficiency. - Energy Monitoring:
With its capability to track electric current, the XL260 device is well-suited for energy monitoring applications. It can measure power consumption in residential or commercial buildings, enabling users to identify energy inefficiencies and make informed decisions to optimize energy usage.
Automation Application
The XL260 device enhances automation capabilities in various settings:
- Home Automation
By integrating the XL260 device with other home automation systems, homeowners can remotely control devices based on the collected data. For example, temperature sensors can trigger HVAC systems, electric current measurements can activate or deactivate appliances, and vibration sensors can detect anomalies and alert homeowners. - Industrial Automation:
In industrial automation scenarios, the XL260 device can be used to automate processes based on real-time data. For instance, it can trigger alarms or activate machinery based on predefined thresholds of temperature, electric current, or pressure.
Remote Control Application
The XL260 device enables remote control of external devices:
- Smart Home Control:
Through the device’s relay switch port, users can remotely control external devices, such as lights, fans, or security systems. This enables convenient and efficient management of home systems from a central location or through a mobile application. - Industrial Applications:
The XL260 device’s remote-control capabilities find application in industries where controlling external devices is essential, such as controlling pumps, valves, or machinery in remote locations.
